The M12 X-coding connector conforms to IEC 61076-2-109; it meet Cat 6A specifications with data transmission rates up to 10 Gbps, these high-speed connectors are designed for industrial communications and networks, video surveillance and other applications requiring a fast and reliable Ethernet connection. CABLEFORCE offers M12 X-Coding cable molded cordsets and M12 X-Coding PCB panel mount receptacles as well as male M12 X-Code to RJ45 male connector with different customized cable material and cable specifications.
● Cable available with PUR, PVC, LSZH, NFPA130 material
● Custom cable specification and lengths
● Rated: 48V/ 0.5A
● Up to 500Mhz/ 10Gbps
● Protection degree IP67
● 特制柔韧材质电缆满足:移动布线拖链耐弯曲与耐磨等要求
● 优异的芯线裁线剥芯与焊接工艺
● 实心黄铜镀镍螺丝,带防振松设计,通过48小时盐雾测试
● 抗紫外线、抗水解、耐油
● 使用温度范围: 动态 -25 ~ 80℃, 静态: -40 ~ 80℃
● IP 67、IP68 防护等级,确保在潮湿、水下、室外环境安全使用
● RoHS,REACH 一致性
